Alinco DR-MD500 VHF/UHF DMR Dual Band Transceiver
============================================================
Features
· 4000 Channels, 250 Zones, 250 Scan Lists
· Display DMR ID, Call Sign, Name and Geographical Info
· Allow CSV Export/import of Setting Parameters
· Easy import of DMR Contact Database (Entire World Wide)
· Single or Dual Channel Selectable
· FM Broadcasting Receiver with 100 Memory Channels and VFO
· Manually Programmable Side and Hot Keys
· Automatic Date and Time Calibration by GPS
· X-Band Repeat, Analog Uplink/Digital Downlink or Vice Versa
· Emergency Alarm
· Mixed Mode Operation : Automatically Detects and Switches Between Analog and Digital Modes Depending on The Signal Received
· Recording Time 4 Hours
Digital Mode
· 10.000 Talk Groups, 250 Radio ID, 300.000 Contact Lists
· Display The Caller ID and Name
· 32 Preset Encryption Codes Plus 255 Preset AES 256bit Encryption Codes
· Selective Calls Including Individual, Group or All
· Digital Monitor Function to Receive Signals Without Matching ID or Color Codes
· Plenty of Text Messages 100 Pre-Programmable Short Messages of Up to 200 Characters Each, Capable of Editing Through the Keys Without Using a PC
Analog Mode
· Variety of Signaling; CTCSS/DCS/DTMF/2-TONE/5-TONE Encode and Decode
· Four Different Tone-Burst Tones
· Programmable Auto Repeater Shift in VFO Mode
· Kill & Stun Functions
============================================================
Specifications
GENERAL
Frequency Range : TX/RX 136 – 174MHz / 400 – 480MHz; RX only 76 – 108MHz
Number of Channels : 4000ch
Zones per Radio : 250 zone (MAX 250ch/zone)
Channel Spacing : Analog 12.5/25kHz; Digital 12.5kHz
Operating Voltage : 13.8V DC nominal ±15%
Operating Temperature Range : -20°C to +60°C
Frequency Stability : ±2.0ppm
Antenna Impedance : 50Ω
Dimensions (W x H x D Approx.) with battery pack : 141 x40 188mm
Weight (Approx.) : 1.04 kg
Included : Microphone with DTMF keyboard (EMS-88), Mobile Bracket (ADFM-78), DC Cable (ADU-A38) with Fuse Holder, Spare Fuses (15A) 2pcs, Hardware Kit for Bracket, Mic Hanger, PC Interface Cable (ERW-21)
TRANSMITTER
RF Power Output : VHF : 55W (144-148MHz)/50W/25W/10W/1W; UHF : 40W/25W/10W/1W
Spurious Emission : Less than 1GHz : -36dBm; More than 1GHz : -30dBm
FM Hum & Noise (Analog) : 25kHz : 40dB; 12.5kHz : 36dB
Modulation : Analog : 16K0F3E/11K0F3E; Digital : 7K60FXD/7K60FXE
RECEIVER
Sensitivity (Analog/12dB SINAD) : 25kHz : 0.25µV; 12.5kHz : 0.35µV
Sensitivity (Digital/BER) : 5% : 0.3µV; 1% : 0.7µV
FM Hum & Noise (Analog) : 25kHz : 45dB; 12.5kHz : 40dB
Audio Distortion : Less than 5%
Audio Output : 2W/8Ω
===========================================================
