GW Instek AFG-3051 50MHz Arbitrary Function Generator

============================================================

Features

·         Wide frequency range from 1uHz to 80/50MHz

·         High 200MSa/s sampling rate

·         16-bit Amplitude Resolution

·         Output from any section of 1M-point-long waveform

·         4.3" high-resolution LCD display/on-screen help/Impedance switch

·         Four ways to generate arbitrary waveform: Front Panel Operation

·         CSV file uploading, Direct Waveform Reconstruction (DWR), Arbitrary

·         Waveform Editing PC Software

·         USB, RS-232, GPIB interface support

============================================================

Specifications

WAVEFORMS : Sine, Square, Ramp, Pulse, Noise, DC, Sin(x)/x, Exponential Rise, Exponential Fall, Negative Ramp

ARBITRARY WAVEFORMS

*ARB Function : Built in

*Sample Rate : 200 MSa/s

*Repetition Rate : 100MHz

*Waveform Length : 1M points

*Amplitude Resolution : 16 bits

FREQUENCY CHARACTERISTICS

*Sine, Square : 50MHz

*Triangle, Ramp : 1MHz

*Resolution : 1µHz

DISPLAY : 4.3 inch TFT LCD; 480 x 3(RGB) x 272

INTERFACE : GPIB, RS-232C, USB Host/Device

POWER SOURCE : AC 100 – 240V, 50 – 60Hz, 65VA

DIMENSIONS & WEIGHT : 265 (W) x 107 (H) x 374 (D)mm, Approx. 4kg

ACCESSORIES : CD(User manual+Software) × 1,Quick Start Guide × 1, Power Cord × 1, GTL-110 Test Lead × 1

===========================================================
