GW Instek APS-7050 500VA Programmable AC Power Source
============================================================
Features
· 4.3-inch TFT-LCD
· Output capacity : APS-7050(500VA, 310Vrms, 4.2Arms); APS-7100 (1000VA, 310Vrms, 8.4Arms)
· Low Ripple & Noise
· Measurement and test functions include VOLTCURR、PWR、SVA、IPK、IPKH、FREQ、PF、CF
· Support a small AC current measurement 2mA ~ 35A, Min. resolution 0.01mA(APS- 7050& APS-7100)
· Reverse Current Alarm Function
· 10 sets of Sequence function to Edit Output Waveforms/ 10 sets of simulate mode to Rapidly Simulate Transient Power Supply/ 10 sets of Program mode to Define Measurement Sequence/ 10 sets of Panel Memory Function
· Automatic Execution of Sequence、Simulate、Program mode and Output Function when the Power is on
· Standard Interfaces: LAN, USB Host
============================================================
Specifications
AC OUTPUT
-Power Rating : 500VA
-Output Voltage : 0 – 155Vrms/0 – 310Vrms
-Output Frequency : 45.00 – 500.0Hz
-Maximum Current (r.m.s) :
0 – 155Vrms : 4.2A
0 – 310Vrms : 2.1A
-Maximum Current (r.m.s) :
0 – 155Vrms : 16.8A
0 – 310Vrms : 8.4A
-Total Harmonic Distortion (THD) : ≤ 0.5% at 45 -50Hz (Resistive Load)
-Crest Factor : ≤ 4
-Line Regulation : 0.1% (% of full scale)
-Load Regulation : 0.3% (% of full scale)
-Response Time : <100µs
-Reverse Current : 30% of Maximum Output RMS Current (Continue) 100% of Maximum Output RMS Current (Within 3 minutes)
AC INPUT
-Phase : Single Phase
-Input Voltage : 115/230Vac ±15%
-Input Frequency : 50/60Hz
-Max. Current : 16A/8A
-Power Factor : 0.7 Typ.
-Power Consumption : 1.8kVA or less
INTERFACE : USB Host, LAN
DIMENSIONS & WEIGHT : 430(W) x 88 (H) x 400(D) mm; Approx. 24kg
ACCESSORIES : CD ROM(User Manual, Programming Manual for APS-7000) x 1, Power Cord(Region Dependent), GTL-123 Test Lead
===========================================================
