GW Instek APS-7100E 1000VA AC Power Source
============================================================
Features
· 4.3 inch TFT-LCD Display
· Output Capacity: APS-7050E(500VA, 310Vrms, 4.2/ 2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/ 4.2Arms)
· only 88mm(2U) case height
· Measurement function comprises Voltage, Current, Power, Current(peak), Frequency, Power Factor
· 10 sets of the Test mode simulate power transient output
· 10 sets of Preset allow users to store ten settings
============================================================
Specifications
POWER RATING : 1000VA
OUTPUT VOLTAGE : 0 – 155VRMS/0 – 310VRMS
OUTPUT FREQUENCY : 45 – 500Hz
MAXIMUM CURRENT (R.M.S)
-0 – 155VRMS : 8.4A
-0 – 310VRMS : 4.2A
MAXIMUM CURRENT (PEAK)
-0 – 155VRMS : 33.6A
-0 – 310VRMS : 16.8A
TOTAL HARMonIC DISTORATION (THD) : ≤ 0.5% at 45 – 500Hz (Resistive Load)
CREST FACTOR : ≤ 4
LINE REGULATION : 0.1% (% of full scale)
LOAD REGULATION : 0.3% (% of full scale)
RESPonSE TIME : < 100µS
REVERSE CURRENT : 30% of Maximum Output RMS Current (Continue) 100% of Maximum; Output RMS Current (Within 3 minutes)
GENERAL
-Number of Preset : 10 (0 – 9 Numeric keys)
-Protection : OCP, OPP, OTP and Alarm
AC INPUT
-Input Power Source : 1ศน AC 115/230Vac ±15%
DIMENSIONS & WEIGHT : 430(W) x 88(H) x 560(D) mm; Approx. 38kg
ACCESSORIES : CD ROM (User Manual x 1), Power Cord (Region Dependent), Mains Terminal Cover Set, GTL-123 Test Lead
===========================================================
