GW Instek GBM-3080 80V Battery Meter
============================================================
Features
· 3.5’ TFT LCD (320x240)
· Measurement items: DC voltage and AC resistance
· Voltage measurement: 300V (GBM-3300) or 80V (GBM-3080)
· Resistance measurement: 0mΩ to 3.2kΩ(max.)
· Basic accuracy for voltage measurement: 0.01%
· Basic accuracy for resistance measurement: 0.5%
· Measurement resolution up to 0.1μΩ and 10μV, suitable for single-cell measurement
· Independent GO/NOGO determination function for voltage and resistance respectively
· The judgment mechanism of test lead (probe) disconnect/contact failure is to ensure the measurement reliability
· Standard interfaces: USB host/device, RS-232C and Handler
============================================================
Specifications
DISPLAY : 6 digits 3.5” (320x240) TFT LCD
TEST SPEED
-Slow : 3 time/second
-Medium : 14 time/second
-Fast : 25 time/second
RESISTANCE MEASUREMENT
-Test Frequency : 1kHz (± 0.5Hz) Fixed
-Input Impedance : 3mΩ - 300mΩ : 99kΩ, 3Ω - 3kΩ : 2MΩ
VOLTAGE MEASUREMENT
-Range : 80V
-Resolution : 100µV
-Accuracy : ± 0.01%rdg ± 3dgt
OTHER FUNCTIONS
-Range Selection : Auto range, Hold range, Nom range
-Comparator : ABS, PER or SEQ
-Contact Detection : OPEN & WIRE
-Buzzer : OFF, Pass, Fail
-Trigger : INT, EXT
INTERFACE : USB Host/USB Device/RS-232C/Handler
POWER SOURCE : AC 100-240, 50-60Hz; Consumption: 10W
DIMENSIONS & WEIGHT : 264(W) x 107(H) x 309(D) mm, Approx. 2.8kg
ACCESSORIES : Safety sheet x 1, Power cord x 1, GBM-01 x 1 : 4 Wire(kelvin clip) test lead, 90V(max.), approx. 1100mm, CD x 1(including complete user manual and USB driver)
===========================================================
