GW Instek GDM-8342 50000 counts Dual Measurement Multimeter with USB Host/Device
============================================================
Features
· 50,000 counts, VFD display
· Dual measurement/Dual display
· Selectable measurement speeds, the maximum: 40 Readings/s for DCV
· The basic precision of DC voltage: 0.02%
· Auto/manual Ranging
· True RMS (AC，AC+DC) measurements
· 11 different measurement functions
· Max./Min., REL, MX+B, 1/X, Ref%, Compare, Hold, dB, dBm
· Standard USB device interface to connect with a computer
· Temperature measurement function
· USB storage for Data collection
============================================================
Specifications
DC VOLTAGE
-Range : 500mV – 1000V
-Resolution : 10µV – 100mV
RESISTANCE
-Range : 500Ω - 50MΩ
-Resolution : 10mΩ - 1kΩ
DC CURRENT
-Range : 500µA – 10A
-Resolution : 10nA – 1mA
CONTINUITY
-Range : 500Ω
-Resolution : 100mΩ
DIODE TEST
-Range : 5V
-Resolution : 100µV
CAPACITANCE
-Range : 5nF - 50µF
-Resolution : 0.001nF – 10nF
FREQUENCY : 10Hz – 1MHz
TRUE RMS AC (or AC+DC – AC Coupled) VOLTAGE
-Range : 500mV – 750V
-Resolution : 10µV – 100mV
TRUE RMS AC (or AC+DC – AC Coupled) CURRENT
-Range : 500µA – 10A
-Resolution : 10nA – 1mA
THERMOCOUPLE TEMPERATURE : -200°C - 300°C (J/T/K)
INTERFACE : USB device, USB Host
DISPLAY : VFD, Two Colors Display
POWER SOURCE : AC 100V/120V/220V/240V ±10%, 50-60Hz, Max. 15VA
DIMENSIONS & WEIGHT : 265(W) x 107(H) x 302(D)mm, Approx. 2.9kg
ACCESSORIES : Safety Instruction Sheet x 1, Power cord x 1, Test lead GTL-207A x 1, CD x 1 (including complete user manual, USB driver and PC software)
===========================================================
