GW Instek GDS-1054B 50MHz, 4-Channel Digital Storage Oscilloscope
============================================================
Features
· 50MHz bandwidth selections, 4ch input
· 1GSa/s maximum sampling rate
· 10M maximum memory depth for each channel
· I2C/SPI/UART/CAN/LIN serial bus trigger and decoding functions
· 1Mpts FFT frequency domain signal display
· Zero Key function for horizontal time, vertical voltage and triggering
· Compact and innovative exterior design
============================================================
Specifications
VERTICAL
*Channels : 4Ch + Ext
*Bandwidth : DC-50MHz(-3dB)
*Calculated Rise Time : 7ns
*Bandwidth Limit : 20MHz
*Vertical Resolution : 8 bits : 10mV – 10V/div
*Record Length : Max. 10Mpts
*Real Time Sampling Rate : 1GSa/s max
*Waveform Update Rate : 50,000wfms/s
TRIGGER
*Source : CH1, CH2, CH3, CH4, Line, Ext
*Trigger Mode : Auto (Supports Roll Mode for 100 ms/div and slower), Normal, Single Sequence
EXT TRIGGER
*Range : ±15V
*Sensitivity : DC – 100MHz Approx. 100mV; 100MHz – 200MHz Approx. 150mV
HORIZONTAL
*Time base Range : 1ns/div – 100s/div (1-2-5 increments); ROLL : 100ms/div – 100s/div
*Pre-Trigger : 10 div maximum
DISPLAY : 7” 800 x 480 TFT WVGA color display
INTERFACE : USB Port, Ethernet Port (LAN), Go/NoGo BNC
POWER SOURCE : AC 100V – 240V, 50Hz – 60Hz, auto selection, 30 Watts
DIMENSIONS & WEIGHT : 380(W) X 208(H) X 127.3(D)mm, Approx. 2.8 kg
ACCESSORIES : User manual CD x 1, Power cord x 1, GTP-070B-4 70MHz Passive Probe. Suitable for GDS-1074B,GDS-1072B,GDS-1054B
===========================================================
