GW Instek GDS-3154 150MHz, 4 Channels Digital Storage Oscilloscopes

============================================================

Features

·         150MHz with 4 Channels

·         5GSa/s RT or 100GSa/s ET Sampling Rate

·         Independent Memory for Each Channel

·         VPO Technology

·         Large 8-inch 800x600 Display

·         Split Screen Function

·         3 Built-in Impedances (50Ω/75Ω/1MΩ)

============================================================

Specifications

Bandwidth : DC-150MHz (-3dB)

Channel : 4ch+Ext

Rise Time : 2.3ns

Resolution : 8 bit (1mV – 5V/div)

Input Coupling : AC, DC, GND

Input Impedance : 1MΩ/15pF

DC Gain Accuracy : ±3% full scale

Display : 8” 800 x 600 TFT LCD SVGA Color Display

Interpolation : Sin(x)/x & Equivalent Time Sampling

Waveform Display : Dots, Vectors, Variable Persistance (16ms – 10s), Infinite Persistance

Waveform Update Rate : 3500 Waveforms per Second, Maximum

Interface : RS232C, USB Port, Ethernet Port, Go-NoGo BNC

Operating Temperature : 0°C to 50°C

Power Source : AC 100V – 240V, 48Hz – 63Hz, auto selection

Dimensions (WxHxD) : 400 x 200 x 130 mm

Weight : Approx. 4 kg

Accessories : User manual CD x 1, Power cord x 1, GTP-151R 150MHz(10:1) passive probe for GDS-3152/ 3154 (per channel)

===========================================================
