GW Instek GLC-9000 Leakage Current Tester
============================================================
Features
· Touch Panel with Color LCD Display
· 9 Different Measurement Network to Simulate the Resistance of Human Body
· 8 Different Types of Leakage current
· Various Leakage Current Measuring Mode：DC/AC/AC+DC/AC Peak
· Upper & Lower Limitation for PASS/FAIL Judgment
· Meter Mode with SELV/CONV Function
· 50 Preset Test Conditions Conform to IEC 60990; 30 Sets Memories for Customer Defined
· Various Standard Interfaces：RS232/GPIB/USB Host & Device/EXT I/O
============================================================
Specifications
DC RANGE & RESOLUTION
-25.00mA : 5.00mA – 25.00mA | 10µA
-5.000mA : 0.500mA – 5.000mA | 1µA
-500.0µA : 50.00µA – 500.0µA | 0.1µA
-50.00µA : 4.00µA – 50.00µA | 0.01µA
AC or AC + DC RANGE & RESOLUTION
-25.00mA : 5.00mA – 25.00mA | 10µA
-5.000mA : 0.500mA – 5.000mA | 1µA
-500.0µA : 50.00µA – 500.0µA | 0.1µA
-50.00µA : 4.00µA – 50.00µA | 0.01µA
AC PEAK RANGE & RESOLUTION
-75.0mA : 10.0mA – 25.0mA | 100µA
-10.00mA : 1.00mA – 10.00mA | 10µA
-1.000mA : 500µA – 1.000mA | 1µA
-500.0µA : 40.0µA – 500.0µA | 0.1µA
EUT (V/I CHECK)
-Voltage : 85V – 300V
-Current : 0.5 – 10A
METER MODE
-AC/DC : 10.0 – 300.0V
-AC+DC : 10.0 – 300.0V
-AC Peak : 15.0 – 430.0V
INTERFACE : RS-232, GPIB, USB Host & Device, EXT I/O
POWER SOURCE : For GLC-9000 : AC 100V/120V/220V/230V 10%, 50/60Hz; For EUT : AC 85V ~ 250V, 50/60Hz(264V Max.)
DIMENSIONS & WEIGHT : 330 (W) x 150 (H) x 350 (D) mm; Approx. 5kg
ACCESSORIES : User manual x 1, Power cord x 2, Test lead(GTL-207) x 2, CD x1(Complete user manual), Alligator clips(GLC-01) x 4(Red x 2/Black x 2), Foil probe(GLC-02) x
===========================================================
