GW Instek GOM-805 D.C. Milliohm Meter

============================================================

Features

·         50,000 counts

·         3.5” (320 x 240) TFT LCD display

·         High accuracy of 0.05% precision

·         1Amp test current, 0.1µΩ resolution

·         Fast measurement of 60 readings per second

·         Four wire resistance measurement

·         Temperature compensation measurement function

·         Delayed measurement

·         20 sets of panel setting memory

·         Dry circuit (GOM-805 only)

·         Drive modes (GOM-805) : DC+/DC-, Pulsed, PWM, Zero, Standby

·         Drive modes (GOM-804) : DC+, Standby

·         Interface: USB device, RS-232C, Handler/Scan/EXT I/O, and GPIB (option)

============================================================

Specifications

DISPLAY : 50,000 counts

SAMPLING RATE

-Slow : 10 readings/s

-Fast : 60 readings/s

RESISTANCE MEASUREMENT

-Range : 5mΩ to 5MΩ

-Resolution : 0.1µΩ

-Test Current : 1A

-Accuracy : ±(0.1% reading + 0.2% of range)

TEMPERATURE

-Range : -50°C to 399.9°C

-Accuracy : -10°C to 40°C : 0.3% ±0.5°C; Other : 0.3% ±1.0°C

-Resolution : 0.1°C

DRY CIRCUIT : Open circuit less than 20mV; For 500mΩ, 5Ω, 50Ω range only

DRIVE MODE

-DC+/DC- : Yes

-Pulsed : Yes

-PWM : Yes

-Zero : Yes

-Standby : Yes

OTHER FUNCTIONS : Trigger - Internal, Manual, External; Math – 2-10 times;ABS, REL, %, TC; Average : Measurement Delay; TC for Transformer; Compare; Diode; Continuity beeper

INTERFACE : USB, RS-232C, HANDLER, SCAN, EXT I/O, GPIB

DISPLAY : 3.5” (320 x 240) TFT LCD

MEMORY : 20 sets for panel setting

POWER SOURCE : AC 100 - 240V 10% , 50/60Hz, 25VA (max.)

DIMENSIONS & WEIGHT : 223(W) x 102(H) x 283(D) mm; Approx. 3kg

ACCESSORIES : Quick Start Guide x 1, Power cord x 1, Test lead GTL-308 x 1, CD x1(complete user manual)

===========================================================
