GW Instek GRF-1300A RF and Communication Trainer
============================================================
Features
· baseband Signal: Sine, Triangle, Square wave
· Frequency Range: 0.1 - 3MHz
· RF Frequency: 870 ~ 920MHz
· AM & FM Modulation
· Mixer & 2.4GHz Bandpass Filter
· 5 programmable On/Off Switches and 5 Test Points to Simulate 8 Failure Conditions for Trouble-Shooting Study
· USB Interface to Provide Remote Control
============================================================
Specifications
baseBAND
* Waveforms : Sine, Square, Triangle
*Frequency Range : 0.1 - 3MHz, Step : 10kHz
*Amplitude : ≥1.5Vpp; ≥0.75Vpp into 50 Ohm
*Harmonic Distortion : ≤-30dBc
RF/FM ANALYSIS
*Frequency Accuracy : ±0.15MHz
*Adjustable Range : ≥45MHz (870M - 920MHz) , Step : 1MHz
*Power Range : ≥-15dBm
FM
*Max Frequency Deviation : >3MHz
AM
*Peak Difference : ≥-18dBm
MIXER
*LO + IF : ≥-35dBm
*LO – IF : ≥-35dBm
MIXER + MODULATION : ≥-60dBm
BANDPASS FILTER
*Frequency Centre : 2.4GHz
*Bandwidth : ±20MHz
INTERFACE : USB Type B
DIMENSIONS & WEIGHT : 165(W) x 155(H) x 90(D)mm, Approx. 1.2kg
===========================================================
