GW Instek MDO-2102EX 100MHz, 2Channel Mixed-Domain Oscilloscope,Spectrum Analyzer, Dual Channel 25MHz AWG

============================================================

Features

·         100MHz bandwidth selections; 2 channels

·         Real time sampling rate for each channel is 1GSa/s (2 channel models)

·         MDO-2000EX equips with a spectrum analyzer ; a dual channel 25MHz AWG; DMM and power supply

·         True RMS measurement in DMM function

============================================================

Specifications

VERTICAL SENSITIVITY

*Channels : 2Ch + Ext

*Bandwidth : DC-100MHz(-3dB)

*Calculated Rise Time : 3.5ns

*Bandwidth Limit : 20MHz

*Vertical Resolution : 8 bits : 10mV – 10V/div

*Record Length : 10M/ch

*Real Time Sampling Rate : Per channel 1 Gsa/s

TRIGGER

*Source : CH1, CH2, Line, Ext

*Trigger Mode : Auto (Supports Roll Mode for 100 ms/div and slower), Normal, Single Sequence

SPECTRUM ANALYZER

*Frequency Range : DC-500MHz(Max.) (Max. Bandwidth -500MHz uncalibrated)

*Span : 1kHz – 500MHz(Max.)

AWG

*Channels : 2

*Sample Rate : 200 MSa/s

DMM

*Digit Level : 5,000 counts; CAT II 600Vrms, CAT III 300Vrms

*DC Voltage : 50mV, 500mV, 5V, 50V, 500V, 1000V 6 ranges

POWER SUPPLY

*Output Channel : CH1 & CH2

*Output Voltage Range : 1.0V – 5.0V

DISPLAY : 8” 800 x 480 TFT WVGA color display

INTERFACE : USB Port, Ethernet Port (LAN), Go/NoGo BNC

POWER SOURCE : AC 100V – 240V, 50Hz – 60Hz, auto selection

DIMENSIONS & WEIGHT : 384(W) X 208(H) X 127.3(D)mm, Approx. 3 kg

ACCESSORIES : User manual CD x 1,Power cord x 1, GTL-110 BNC-BNC cable x 2, GTL-105A Alligator Clip test lead, GTL-207A Banana plug test lead, GTP-100B-4 100MHz(10:1/1:1)Switchable passive probe

===========================================================
