GW Instek MFG-2260MRA 60MHz Dual Channel Arbitrary Function Generator with Pulse Generator, Modulation, 320MHz RF Signal Generator, Power Amplifier
============================================================
Features
· Maximum Five Output Channels
· 2 Equivalent Performance Arbitrary Channels Frequency : 1μHz~10/20/30/60/200MHz
· RF Channel Frequency (FG/ARB/MOD) : 160/320MHz
· Pulse Generator Frequency : 25MHz
· Power Amplifier : Low Frequency, 100kHz, Output 20W
· Earth Ground Isolation Design Among I/O Terminals and Instrument Chassis (MFG-2220HM Excluded)
· Frequency Counter : 150MHz, 8 bits Frequency Resolution
· AM/FM/PM/ASK/FSK/PSK/SUM/PWM Modulation
· USB Host/USB Device/LAN (MFG-22XX only)
============================================================
Specifications
WAVEFORMS : Sine, Square, Triangle, Ramp, Pulse, Noise
ARBITRARY FUNCTIONS
*Sample Rate : 200MSa/s
*Repetition Rate : 100MHz
FREQUENCY CHARACTERISTICS
*Range : 60MHz (CH1); 60MHz (CH2)
*Resolution : 1µHz
RF GENERATOR
*Range : 1µHz – 320MHz(DDS)/1µHz – 60MHz(ARB)
*Resolution : 1µHz
PULSE GENERATOR
*Frequency : 1µHz – 25MHz
*Pulse Width : 20nS – 999.7ks
BURST
*Frequency : 25MHz (sine, square); 1MHz (triangle, ramp)
*Pulse Count : 1 – 1000000 Cycles or intfinite
FREQUENCY COUNTER
*Range : 5Hz – 150MHz
*Accuracy : Time base accuracy ± 1 count
DISPLAY : 4.3 inch TFT LCD, 480 x 3 (RGB) x 272
INTERFACE : LAN, USB
POWER SOURCE : AC 100 – 240V, 50 – 60Hz
DIMENSIONS & WEIGHT : 266 (W) x 107 (H) x 293 (D) mm, Approx. 2.5kg
ACCESSORIES : Quick Start Guide x 1, CD-ROM with MFG Software and User Manual x 1, GTL-101 BNC-Alligator test lead x 2
===========================================================
