GW Instek MSO-2202EA 200MHz, 2 + 16 Channel Mixed-Signal Oscilloscope
============================================================
Features
· 200MHz bandwidth selections: 2 channels
· MSO-2000EA equips with a 16-channel logic analyzer and a dual channel 25MHz arbitrary waveform generator
· Real time Sampling rate for each channel is 1GSa/s
· Maximum 10M memory depth and VPO waveform display technology
· Waveform update rate up to 120,000 wfms/s
· 29,000 segmented memory sections and waveform search function
============================================================
Specifications
VERTICAL SENSITIVITY
*Channels : 2Ch+Ext
*Bandwidth : DC-200MHz(-3dB)
*Calculated Rise Time : 1.75ns
*Bandwidth Limit : 20M/100MHz
*Vertical Resolution : 8 bits : 1mV – 10V/div
TRIGGER
*Sources : CH1, CH2, Line, EXT
*Modes : Auto (Supports Roll Mode for 100 ms/div and slower), Normal, Single Sequence
EXTERNAL TRIGGER
*Range : ±15V
*Sensitivity : DC - 100MHz Approx. 100mV; 100MHz - 200MHz Approx. 150mV
HORIZONTAL
*Timebase Range : 1ns/div - 100s/div (1‐2‐5 increments); ROLL : 100ms/div - 100s/div
*Pre‐trigger : 10 div maximum
LOGIC ANALYZER
*Sample Rate : 1GSa/s
*Bandwidth : 200MHz
AWG SPECIFICATIONS
*Channels : 2
*Sample Rate : 200MSa/s
DISPLAY : 8” TFT LCD 800 x 480 WVGA Color Display
INTERFACE : USB Port, Go-NoGo BNC, Ethernet Port (LAN)
POWER SOURCE : AC 100V – 240V, 50Hz – 60Hz, Auto Selection
DIMENSION & WEIGHT : 384(W) X 208(H) X 127.3(D)mm, Approx. 2.8 kg
ACCESSORIES : User Manual CD x 1, Power Code x 1, GCP-201 Probe Clips 20pcs, GTL-16E 16-Channel Logic Analyzer Probe, GTP-200B-4 200MHz(10:1/1:1)Switchable passive probe for MSO-2202E(A)/2204E(A)(one per channel)
===========================================================
