GW Instek PLR 20-18 (0-20V/0018A/360W) Low Noise DC Power Supply
============================================================
Features
· Output Voltage Rating : 20V/36V/60V
· Output Power : 360W/720W
· Low Ripple and Noise (0.5mVrms/ 10mArms)
· Fast transition recovery time (100us)
· Maximum 2 units in series connections or 3 units in parallel connections
· Select the setting digits for voltage and current (coarse/ fine volume control)
· Panel Lock Function
· 3 set of preset function
· Output off timer function (Range:1 min to 1000 hours & 59mins)
· CC priority function (prevent overshoot & inrush current)
· Sequence function of PC editing (Max. : 1000 steps/ Min. step period : 50ms)
· Protection: OVP, UVP, OCP, remote sensing (Terminal open)
· External Analog Control Function
· PC Remote Interface (Standard : RS-232)
· CE Compliance
============================================================
Specifications
OUTPUT RATING
*Voltage : 0V – 20V
*Current : 0 – 18A
*Power : 360W
REGULATION (CV)
*Load : 3mA
*Line : 2mA
REGULATION (CC)
*Load : 5mA
*Line : 5mA
RIPPLE & NOISE (Noise Bandwidth=20MHz; Ripple Bandwidth=1MHz)
*CV p-p : 30mVp-p
*CV rms : 0.5mVrms
*CC rms : 10mArms
SETTING RESOLUTION
*Voltage : 10mV
*Current : 10mA
MEASUREMENT RESOLUTION
*Voltage : 10mV
*Current : 10mA
SERIES AND PARALLEL CAPABILITY
*Parallel Operation : Up to 3 units
*Series Operation : Up to 2 units
INTERFACE : RS-232/Local bus
POWER ConSUMPTION : 570VA
POWER FACTOR : 0.99
POWER SOURCE : Single-phase 100VAC to 240VAC, 50Hz to 60Hz
DIMENSIONS & WEIGHT : 140 (W) x 139.5 (H) x 415.5 (D) mm, Approx. 5.2kg
ACCESSORIES : User Manual(CD) x 1, Power Cable x 1, Rear Output Terminal Cover x 1, Bolt set x 1(Hexagon head bolt P-3 x 2, Flat washer x 2, Hexagon nut x 2), Output grounding cable x 1, M4 Small Screw Washer x 1, M3 Small Screw Washer x 1, M3 Large Screw Washer x 2
===========================================================
