GW Instek PSB-1400L 40V/40A/400W Programmable Multi-Range D.C. Power Supply
============================================================
Features
· LCD display and menu-typed functionality selection
· Support front panel output terminals (Max.30A) and rear panel output terminals (Rating current output)
· Bleeder circuit control
· I/V Control function
· Sequence function
· Power on Configuration
· Internal Sense Control( Disable/ front panel/ rear panel)
· Voltage trigger function
· Output delay function
· OCP Control function
· Interface: USB Host
============================================================
Specifications
OUTPUT RATING
-Voltage : 40V
-Current : 40A
-Power : 400W
REGULATION (CV)
-Load : 25mV
-Line : 23mV
REGULATION (CC)
-Load : 45mA
-Line : 45mA
RIPPLE AND NOISE (Noise Bandwidth 20MHz; Ripple Bandwidth = 1MHz)
-CV p-p : 60
-CV rms : 7
-CC rms : 80
PROGRAMMING & MEASUREMENT ACCURACY
-Voltage : 10mV
-Current : 20mA
RESPonSE TIME
-Raise Time : 50ms
-Fall Time (Full load) : 50ms
-Fall Time (No load) : 500ms
-Load Transient Recover Time (Load change from 50-100%) : 1ms
PROGRAMMING & MEASUREMENT RESOLUTION
-Voltage : 1mV
-Current : 1mA
SERIES & PARALLEL CAPABILITY
-Parallel Operation : Up to 4 units including the master unit
-Series Operation : Up to 2 units including the master unit
INTERFACE : USB, LAN
POWER SOURCE : 100VAC to 240VAC, 50Hz to 60Hz, single phase
DIMENSIONS & WEIGHT : 214(W) x 124(H) x 350(D)mm, Approx. 5.2kg
ACCESSORIES : CD ROM (User & Programming Manual) x 1, Power cord for UL/CSA or PSE (Region Dependent), Output terminal cover, Type A-B USB cable, Analog connector plug set, Chassis connection wire
===========================================================
