GW Instek PSU 300-5 1500W Programmable Switching DC Power Supply
============================================================
Features
· Voltage Rating : 6V/8V/12.5V/15V/20V/30V/40V/50V/60V/80V/100V/150V/300V/400V/600V
· Output Power Rating: 1200W-1560W
· C.V / C.C Priority
· Adjustable voltage/current rise and fall time
· Series/ Parallel Connection: Max. 2 Units(Models Under 300V)/ 4 Units of The Same Model
· High Efficiency and High Power Density
· 1U Height and 19”Rack Mount Size
· Standard Interface: USB, LAN, RS-232, RS-485, Analog Control
============================================================
Specifications
OUTPUT RATING
-Voltage : 300V
-Current : 5A
-Power : 1500W
RIPPLE AND NOISE
-CVp-p (10 – 20MHz) p.p : 150mV
-CVrms (5Hz – 1MHz) r.m.s. : 25mV
-CCrms (5Hz – 1MHz) r.m.s. : 25mA
LOAD REGULATION
-Voltage : 32mV
-Current : 6mA
LINE REGULATION
-Voltage : 32mV
-Current : 2.5mA
TRANSIENT RESPonSE TIME : 2ms
REMOTE SENSE COMPENSATION VOLTAGE (TWO WIRE) : 5V
INTERFACE : USB, LAN, RS-232/RS-485
POWER SOURCE : 100VAC to 240VAC, 50Hz to 60Hz, single phase
DIMENSIONS & WEIGHT : 423(W) x 43.6(H) x 447.2(D)mm, Approx. 8.7kg
ACCESSORIES : CD-ROM x 1(User Manual, Programming Manual), Output terminal cover x 1, Analog connector plug kit x 1, Output terminal M8 bolt set (6V-60V model), Input terminal cover x 1, 1U Handle(RoHS), 1U Bracket (LEFT, RoHS), 1U Bracket (RIGHT, RoHS), Power Cord (10A) provided for certain regions only
===========================================================
