GW Instek PSU 400-3.8 1520W Programmable Switching DC Power Supply

============================================================

Features

·         Voltage Rating : 6V/8V/12.5V/15V/20V/30V/40V/50V/60V/80V/100V/150V/300V/400V/600V

·         Output Power Rating: 1200W-1560W

·         C.V / C.C Priority

·         Adjustable voltage/current rise and fall time

·         Series/ Parallel Connection: Max. 2 Units(Models Under 300V)/ 4 Units of The Same Model

·         High Efficiency and High Power Density

·         1U Height and 19”Rack Mount Size

·         Standard Interface: USB, LAN, RS-232, RS-485, Analog Control

============================================================

Specifications

OUTPUT RATING

-Voltage : 400V

-Current : 3.8A

-Power : 1520W

RIPPLE AND NOISE

-CVp-p (10 – 20MHz) p.p : 200mV

-CVrms (5Hz – 1MHz) r.m.s. : 40mV

-CCrms (5Hz – 1MHz) r.m.s. : 17mA

LOAD REGULATION

-Voltage : 42mV

-Current : 5.76mA

LINE REGULATION

-Voltage : 42mV

-Current : 2.38mA

TRANSIENT RESPonSE TIME : 2ms

REMOTE SENSE COMPENSATION VOLTAGE (TWO WIRE) : 5V

INTERFACE : USB, LAN, RS-232/RS-485

POWER SOURCE : 100VAC to 240VAC, 50Hz to 60Hz, single phase

DIMENSIONS & WEIGHT : 423(W) x 43.6(H) x 447.2(D)mm, Approx. 8.7kg

ACCESSORIES : CD-ROM x 1(User Manual, Programming Manual), Output terminal cover x 1, Analog connector plug kit x 1, Output terminal M8 bolt set (6V-60V model), Input terminal cover x 1, 1U Handle(RoHS), 1U Bracket (LEFT, RoHS), 1U Bracket (RIGHT, RoHS), Power Cord (10A) provided for certain regions only

===========================================================
