GW Instek PSW 250-4.5 (0-250V/0-4.5A/360W) Multi-Range DC Power Supply
============================================================
Features
· Voltage Rating: 30V/40V/80V/160V/250V/800V, Output Power Rating: 360W ~ 1080W
· Multi-range Voltage & Current Combinations in One Power Supply
· CV/CC Priority; Particularly Suitable for the Battery and LED Industry
· Adjustable Slew Rate
· Series Operation (2 units in Series) for (30V/40V/80V/160V)
· Parallel Operation (to 3 units Parallel) for (30V/40V/80V/160V/250V/800V)
· High Efficiency and High Power Density
· 1/2, 1/3, 1/6 Rack Mount Size Design (EIA/JIS Standard) for 360W, 720W, 1080W
· Standard Interface: LAN,USB,Analog Control Interface
· LabView Driver
============================================================
Specifications
OUTPUT RATING
-Voltage : 0V – 250V
-Current : 0 – 4.5A
-Power : 360W
REGULATION (CV)
-Load : 130mV
-Line : 128mV
REGULATION (CC)
-Load : 9.5mA
-Line : 9.5mA
RIPPLE & NOISE (Noise Bandwidth=20MHz; Ripple Bandwidth=1MHz)
-CV p-p : 80mV
-CV rms : 15mV
-CC rms : 10mA
PROGRAMMING & MEASUREMENT ACCURACY
-Voltage : 0.1% + 100mV
-Current : 0.1% + 5mA
PROGRAMMING & MEASUREMENT RESOLUTION (By PC Remote Control Mode)
-Voltage : 5mV
-Current : 1mA
INTERFACE : LAN, USB, Analog Control
POWER SOURCE : 85VAC – 265VAC, 47 – 63Hz, single phase
DIMENSIONS & WEIGHT : 214 (W) x 124 (H) x 350 (D) mm, Approx. 7.5kg
ACCESSORIES : CD-ROM x 1, (GTL-123 Test Lead x 1 (for PSW 30V/40V/80V/160V), Power Cord x 1 Programming Manual, User Manual), GTL-240 USB Cable ”L“ Type x 1, PSW-004 Basic Accessories Kit x 1 (for PSW 30V/40V/80V/160V), Includes : M4 Terminal screws and washers x 2, Air Filter x 1, Analog control protection dummy x 1, Analog control lock lever x 1, M8 terminal bolts, nuts and washers x 2
===========================================================
