YAESU VX-8DR 5W Submersible Triple Band Handheld Transceiver

============================================================

Features

·         Submersible to 3 feet (1m) for 30 minutes : Equivalent to the IPX7 Rating

·         Ultra-Rugged Polycarbonate Resin Front Panel with Aluminum die-cast chassis – Absolutely Tougher than Tough!

·         The large main dial and the four durable independent key buttons on the side permit easy operation, even when wearing gloves

·         Large Frequency and Information LCD Display, TX/RX Busy Indication, Easy Band Selection, and a Bright White LED!

·         A Large High-resolution Dot Matrix LCD Display – (about 35 x 18 mm)

·         Memory Stations may be displayed with up to 16 digit Alpha-numeric Tags

·         CW Training Feature, Emergency Automatic ID system, Emergency Strobe/Beep Feature, and Busy Strobe LED Function when Receiving messages.

·         Integrated High-Performance APRS Operation

·         Optional GPS Operation

·         APRS 1200/9600 bps Data Communication (B band only)

·         Real Dual HAM Band Operation (V+V/U+U/V+U)

·         Wideband Receive for 500kHz – 999.990MHz

·         Internal Bar Antenna for better AM Broadcast Band Reception

·         Dual Band AF Dual Monitor Function

·         Built-in Barometric Pressure and Temperature Sensors

·         1267 Memory Channels. Assign 24 Memory Banks up to 100 channels each

============================================================

Specifications

GENERAL

Frequency Range :

*A (Main) Band RX :

- 0.5 – 1.8 MHz (AM Radio)

- 1.8 – 30 MHz (SW Radio)

- 30 – 76 MHz (50 MHz HAM)

- 76 – 108 MHz (FM Radio)

- 108 – 137 MHz (Air Band)

- 137 – 174 MHz (144 MHz HAM)

- 174 – 222 MHz (VHF-TV)

- 222 – 420 MHz (General 1)

- 420 – 470 MHz (430 MHz HAM)

- 470 – 800 MHz  (UHF TV)

- 800 – 999.90 MHz (General 2)

*B (Sub) Band RX :

- 30 – 76 MHz (50 MHz HAM)

- 108 – 137 MHz (Air Band)

- 137 – 174 MHz (144 MHz HAM)

- 174 – 222 MHz (VHF-TV)

- 222 – 420 MHz (General 1)

- 420 – 580 MHz (430 MHz HAM)

*TX :

- 50 – 54 MHz or 50 – 52 MHz

- 144 – 146 MHz or 144 – 148 MHz

- 430 – 440 MHz or 430 – 450MHz

Channel Steps : 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 50, 100 kHz

Frequency Stability : ±5ppm -10°C to +60°C

Repeater Shift :

- ±600 kHz (144 MHz)

- ±1.6 MHz (222 MHz)

- ±1.6/5.0/7.6 MHz (430 MHz)

Antenna Impedance : 50 Ohms

Supply Voltage :

- Nominal : 7.4V DC, Negative Ground (SBR-14LI)

- Operating : 4 – 16V DC, Negative Ground (EXT DC JACK)

- Operating while Charging : 11 – 16V DC (Negative Ground, EXT DC JACK)

Current Consumption (@7.4V DC, approx.) :

- 200 mA (Mono band Receive)

- 240 mA (Dual band Receive)

- 85 mA (Mono band Receive, Standby, Saver Off)

- 120 mA (Dual band Receive, Standby, Saver Off)

- 35 mA (Mono band Receive, Standby, Saver On “Save Ration 1:5”)

- 42 mA (Dual band Receive, Standby, Saver On “Save Ration 1:5”)

- 300 µA (Auto Power Off)

- 1.6 A (50 MHz, 5W TX)

- 1.7 A (144 MHz, 5W TX)

- 1.9 A (430 MHz, 5W TX)

Operating Temperature : -20°C to +60°C

Case Size : 60 (W) x 95 (H) x 24.2 (D) mm (w/o knob, antenna & belt clip)

Weight (approx.: 240g with FNB-101LI & antenna

Included : Rechargeable Lithium Ion Battery Pack (FNB-101LI 7.4V/1.100mAh), Battery Charger (NC-86C), Belt Clip

TRANSMITTER

RF Power Output :

*50/144/430 MHz :

- 5.0 W (@ 7.4V or EXT DC)

- 1.5 W (@ 4.5V : AA x 3)

- L3 : 2.5 W, L2 : 1 W, L1 : 0.05 W

*50 MHz :

- AM : 1 W Fixed

Modulation Type :

- F2E, F3E : Variable Reactance Modulation

- A3E : Low Level Amplitude Modulation (50 MHz only)

Maximum Deviation : ±5 kHz (F2E/F3E)

Spurious Emission :

- At least 60 dB below (@ TX Power Hi/L3/L2)

- At least 50 dB below (@ TX Power L1)

Microphone Impedance : 2k Ohms

RECEIVER

Circuit Type :

- AM, NFM : Double-Conversion Super heterodyne

- WFM : Triple-Conversion Super-heterodyne

- AM/FM : Single-Conversion Super-heterodyne

Intermediate Frequencies :

- NFM, AM 1st : 47.25 MHz (A (Main) Band), 46.35 MHz (B (Sub) Band)

- 2nd : 450 kHz

- WFM 1st : 45.8 MHz/2nd : 10.7 MHz/3rd : 1 MHz

- AM/FM Radio : 130 kHz

Sensitivity :

*A Band :

- 3.0 μV for 10 dB S/N (0.5 – 30 MHz @AM)

- 0.35 μV (TYP) for 12 dB SINAD (30 – 54 MHz @NFM)

- 1.0 μV (TYP) for 12 dB SINAD (54 – 76 MHz @NFM)

- 1.5 μV (TYP) for 12 dB SINAD (76 – 108 MHz @WFM)

- 1.5 µV (TYP) for 12 dB SINAD (59 – 108 MHz @WFM)

- 1.5 µV (TYP) for 10 dB SN (108 – 137 MHz @AM)

- 0.2 µV for 12 dB SINAD (137 – 140 MHz @NFM)

- 0.16 µV for 12 dB SINAD (140 – 150 MHz @NFM)

- 0.2 µV for 12 dB SINAD (150 – 174 MHz @NFM)

- 1.0 µV for 12 dB SINAD (174 – 222 MHz @WFM)

- 0.5 µV for 12 dB SINAD (300 – 350 MHz @NFM)

- 0.2 µV for 12 dB SINAD (350 – 400 MHz @NFM)

- 0.18 µV for 12 dB SINAD (400 – 470 MHz @NFM)

- 1.5 µV for 12 dB SINAD (470 – 540 MHz @WFM)

- 3.0 µV (TYP) for 12 dB SINAD (540 – 800 MHz @WFM)

- 1.5 µV (TYP) for 12 dB SINAD (800 – 999.90 MHz @NFM)

*B Band :

- 0.18 µV (TYP) for 12 dB SINAD (50 – 54 MHz)

- 0.18 µV for 12 dB SINAD (144 – 148 MHz)

- 0.2 µV (TYP) for 12 dB SINAD (430 – 450 MHz)

Selectivity :

- 12 kHz/35 kHz (-6 dB/-60 dB : NFM, AM)

- 200 kHz/300 kHz (-6 dB/-20dB : WFM)

AF Output :

- 200 mW @ 8 Ohms for 10 % THD (@ 7.4V DC)

- 400 mW @ 8 Ohms for 10 % THD (@ 13.8V DC)

===========================================================
